CBU-PWM4

      • Specifications

        Input

        Voltage range：12-24 VDC

        Max. input current：6 A

        No-load standby power：< 0,3 W

        Output

        Output voltage：same as input voltage

        Max. output power：144 W @ 24 VDC；72 W @ 12 VDC

        Max. output current：6 A (can be freely divided between the channels)

        Min. load requirement：0 W

        Dimming method：Pulse Width Modulation (PWM)

    Features:

    CBU-PWM4 is a Bluetooth controllable, Casambi enabled four channel PWM dimmer for constant voltage LED loads, such as LED strips and constant voltage LED modules. It is connected between a 12-24 VDC power supply and the constant voltage LED load.

    CBU-PWM4 can control up to four channels making it an ideal partner for RGBW and tunable white (TW) applications. The maximum total output current is 6 A which can be freely divided between 1-4 channels. CBU-PWM4 is protected against overvoltage, overcurrent and short circuit situations. CBU-PWM4 is not protected against reverse polarity!

    CBU-PWM4 can be controlled with Casambi app which can be downloaded free of charge from Apple App Store and Google Play Store.

    Different Casambi enabled products can be used from a simple one luminaire direct control to a complete and full featured light control system where up to 250 units form automatically an intelligent mesh network.
